Support engine and alternator monitoring,measurement and protection.This is long-running and
           Control System          back-up unit to integrate the best way to control。 support Modbus standard,modem,RS232、
                                   RS485、USB and  internet。



       Measurement, displayment             MRS10 MRS16 AMF20 AMF25       InteliLite NT  MRS 10  3 configurable analog inputs
       Genset prime power Kw                  ●     ●      ●     ●                Mode  Mode  Start  magnetic pickup input
                                                                                          I
                                                                                  Horn  Fault reset  Stop
                                                                                  reset
       Power factor                           ●     ●      ●     ●                       0    D+ preexcitation terminal
                                                                              Page
                                                                                        G     6 binary inputs
       engine speed                           ●     ●      ●     ●            Enter
       Phase to neutral voltage               ●     ●      ●     ●                            6 binary outputs
       Phase to phase voltage                 ●     ●      ●     ●      MRS 10
                                                                        MANUAL AND REMOTE
       Genset frequency                       ●     ●      ●     ●      START CONTROLLER
       Genset current                         ●     ●      ●     ●
       Mains Phase to neutral voltage         ×     ×      ●     ●
                                                                                              3 configurable analog inputs
       Mains Phase to phase voltage           ×     ×      ●     ●        InteliLite NT  MRS 10
                                                                                  Mode  Mode  Start  magnetic pickup input
       Mains frequency                        ×     ×      ●     ●                Horn  Fault      I Stop
                                                                                    reset
                                                                                  reset
                                                                                         0    D+ preexcitation terminal
       engine oil pressure                    ●     ●      ●     ●            Page
                                                                                        G     6 binary inputs
       engine water temperature               ●     ●      ●     ●            Enter   I / 0
                                                                                              6 binary outputs
       fuel level                             ●     ●      ●     ●      MRS 16
       battery voltage                        ●     ●      ●     ●      MANUAL AND REMOTE     GCB control
       genset power KVA                       ●     ●      ●     ●      START CONTROLLER      CAN with J1939 support
                                                                        WITH SUPPORT FOR      extension modules capability
       Genset running time                    ●     ●      ●     ●
                                                                        EFI ENGINES           event and performance log
       Genset output KWh                      ×     ●      ×     ●
       History file                           ×     ●      ×     ●
       Alarm, shutdown function
                                                                                              3 configurable analog inputs
       Low oil pressure warning,shutdown      ●     ●      ●     ●        InteliLite NT  AMF 20
                                                                                  Mode  Mode  Start  magnetic pickup input
       High water temperature warning,shutdown  ●   ●      ●     ●                Horn  Fault reset      I Stop
                                                                                  reset
                                                                                         0    D+ preexcitation terminal
       Engine over and under speed shutdown   ●     ●      ●     ●            Page      G
                                                                              Enter  I / 0  I / 0  7 binary inputs
       Low fuel level warning,shutdown        ●     ●      ●     ●
                                                                                              7 binary outputs
       battery low and high voltage warning   ●     ●      ●     ●      AMF 20                GCB and MCB control
       battery chargering failure             ●     ●      ●     ●      AUTOMATIC MAINS
       Genset low and high voltage warning, shut down  ●  ●  ●   ●      FALURE START
                                                                        CONTROLLER
       Alternator 3 phase voltage unbalance shut down  ●  ●  ●   ●
       Alternator low and high frequency warning,shut down  ●  ●  ●  ●
       Genset over load shutdown              ●     ●      ●     ●
       Alternator3 phase current unbalance shutdown  ●  ●  ●     ●                            3 configurable analog inputs
       Mains low and high voltage warning     ×     ×      ●     ●        InteliLite NT  AMF 20
                                                                                    Mode
                                                                                  Mode
                                                                                          I Start  magnetic pickup input
       Mains low and high frequency warning   ×     ×      ●     ●                Horn  Fault reset  Stop    0  D+ preexcitation terminal
                                                                                  reset
       Optional                                                               Page      G
                                                                              Enter  I / 0  I / 0  7 binary inputs
       Remote start and stop                  ●     ●      ●     ●                            7 binary outputs
       RS232 card                             ○     ○      ○     ○      AMF 25                GCB and MCB control
       USB card                               ○     ○      ○     ○      AUTOMATIC MAINS
                                                                        FAILURE START         CAN with J1939 support
       RS485 card                             ○     ○      ○     ○      CONTROLLER WITH       extension modules capability
       Multi language display                 ○     ○      ○     ○      SUPPORT FOR           event and performance log
                                                                        EFI ENGINE
       GPRS communication                     ○     ○      ○     ○
       GPS communication                      ○     ○      ○     ○
       ●  Standard     ○ Optional    × None
